Inspired By water,made for pool.

Smart-Controlled Electrolytic Salt Chlorinator

Share to:

EC Series Smart-Controlled Electrolytic Salt Chlorinator

The EC Series salt water chlorinator is designed for residential and semi-commercial pools, converting dissolved salt into chlorine to maintain consistent water sanitation. By automatically generating chlorine directly within the circulation system, the unit helps maintain clean pool conditions while minimizing manual chemical dosing and routine intervention.

The compact pool chlorine generator integrates the control panel and electrolysis cell into a single housing, allowing installation in limited equipment spaces while maintaining clear operational access. A removable titanium electrode cell supports convenient inspection and cleaning, helping maintain stable chlorine production during regular pool operation.

Engineered as a complete saltwater pool system, the EC Series operates by passing salted pool water through the electrolytic cell to continuously produce chlorine during circulation. This process maintains consistent disinfection levels while supporting reliable operation for residential pools and light commercial aquatic facilities.

Availability:

Quantity:



Inquire Add to Basket

Model:
EC Series
Brand:
Astrowave Pool

Product Description

A smart-controlled electrolytic salt chlorination system for automated and eco-friendly pool water sanitization.

Product Description

The EC Series salt water chlorinator is designed for residential and semi-commercial pools, converting dissolved salt into chlorine to maintain consistent water sanitation. By automatically generating chlorine directly within the circulation system, the unit helps maintain clean pool conditions while minimizing manual chemical dosing and routine intervention. The compact pool chlorine generator integrates the control panel and electrolysis cell into a single housing, allowing installation in limited equipment spaces while maintaining clear operational access. A removable titanium electrode cell supports convenient inspection and cleaning, helping maintain stable chlorine production during regular pool operation. Engineered as a complete saltwater pool system, the EC Series operates by passing salted pool water through the electrolytic cell to continuously produce chlorine during circulation. This process maintains consistent disinfection levels while supporting reliable operation for residential pools and light commercial aquatic facilities.

Product Features

Integrated Structure: Control panel and chlorine generator are combined into a single compact unit, reducing installation space requirements and simplifying plumbing layout.
Smart Monitoring and Alarm System: Built-in alerts monitor salinity levels and system conditions, helping operators quickly identify issues within an automatic pool chlorinator.
Adjustable Chlorine Production Control: The control panel allows users to adjust chlorine generation levels according to pool usage and water conditions.
Removable Titanium Electrode Cell: The electrolytic cell can be removed for inspection and cleaning, simplifying routine maintenance and extending operational reliability.
Integrated Salt Chlorination Process: The system operates as a saltwater chlorination system that converts dissolved salt into chlorine during water circulation.
Standard Pipe Compatibility: Designed with 1.5 inch / 50 mm pipe connections to support common swimming pool plumbing installations.

Product Specifications

Model	Working Voltage	Working Current	Chlorine Generation	Connection	Recommende Pool Size
EC8	DC 24V	4 Z	8 g/H	1.5" / 50mm	<40 m³ (10,567 gallons)
EC12	DC 24V	4 Z	12 g/H	1.5" / 50mm	<60 m³ (15,850 gallons)
EC16	DC 24V	4 Z	16 g/H	1.5" / 50mm	<80 m³ (21,134 gallons)
EC20	DC 24V	4 Z	20 g/H	1.5" / 50mm	<100 m³ (26,417 gallons)

Dimensions

PICTURE_ONLY

Application Areas

Residential backyard swimming pools where an inground pool chlorinator supports automated sanitation without frequent chemical dosing.
Small resort or boutique hotel pools requiring reliable chlorine generation as part of a pool salt system.
Private villa pools where continuous circulation supports stable water quality and clear swimming conditions.
Apartment complex swimming pools using a pool water sanitizer to maintain daily water disinfection during filtration cycles.
Fitness club and spa pools where automated chlorination helps pool sanitation improve while reducing manual maintenance.
Small community aquatic facilities operating compact salt-based water treatment equipment.

FAQ

How does a salt chlorinator work in a swimming pool?

A salt chlorinator converts dissolved salt in pool water into chlorine through an electrolytic process inside the cell, continuously disinfecting the water during circulation.

Is the EC Series suitable for residential pools?

Yes. The EC Series is designed for residential and light commercial installations, providing automated chlorine generation with a compact installation footprint.

Does the system require regular maintenance?

The electrolytic cell is removable, allowing inspection and cleaning when necessary to maintain stable chlorine generation and system performance.

What type of pools can use this system?

The unit can be installed as part of a saltwater chlorination setup for residential backyard pools, small hotel pools, and other light commercial aquatic facilities.

Can the chlorinator operate automatically?

Yes. The device functions as an automatic pool chlorinator, generating chlorine continuously as pool water passes through the electrolysis cell.

What is the purpose of the salt chlorination system?

The system forms part of a saltwater chlorination system that maintains consistent sanitation levels by converting dissolved salt into chlorine during filtration.
